Miniature Circuit Breaker 63A 1 Pole | 6kA D Curve | DIN Rail by NHP
Miniature circuit breaker with 63A rated current and D curve—ideal for high inrush current applications. Built for residential, commercial, and industrial use, with 6kA short circuit capacity for reliable protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 6kA 1 Pole 63A D Curve
Brand: NHP
SKU: DTM6163D
Alternatively Known As: Miniature Circuit Breaker, MCB, 63A Circuit Breaker, DIN Rail Circuit Breaker
Technical Specifications
- Rated Current: 63 A
- Number of Poles: 1
- Trip Curve: D
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: DC
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-35 mm²
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -25-55 °C
- Dimensions (H x L x W): 85mm x 75mm x 17.5mm
- Weight: 0.12 kg
Key Features
- Rated current of 63A with a D curve for high inrush current applications.
- 6kA short circuit breaking capacity for reliable protection.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60898 and AS/NZS 60947 for safety and performance standards.
Environmental Benefits
- Enhances electrical safety, reducing the risk of fire hazards.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker MCB 6kA 1 Pole 63A D Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
