Miniature Circuit Breaker 63A | 6kA 1 Pole C Curve | IP40 Rated by NHP
Miniature circuit breaker with 63A rated current and C curve for overload protection—ideal for residential and commercial applications. Built for safety, with 6kA short circuit capacity and IP40 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP MOD6+ Miniature Circuit Breaker MCB 6kA 1 Pole 63A C Curve
Brand: NHP
SKU: MD6M163
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Rated Current: 63 A
- Number of Poles: 1
- Trip Curve: C
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC
- Rated Short Circuit Breaking Capacity: 6 kA
- Max Rated Operation Voltage: 440 V
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Degree of Protection: IP40
- Connectable Conductor Cross Section (Solid Core): 0.75-25 mm²
- Connectable Conductor Cross Section (Multi-Wired): 0.75-16 mm²
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -25-70 °C
- Dimensions (H x L x W): 85mm x 75.8mm x 17.5mm
- Weight: 0.12 kg
Key Features
- Rated current of 63A with a C curve for overload protection.
- 6kA short circuit breaking capacity.
- IP40 rated for protection against solid objects.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
- Efficient circuit protection reduces the risk of electrical fires and equipment damage.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP MOD6+ Miniature Circuit Breaker MCB 6kA 1 Pole 63A C Curve is available now for immediate purchase. Ideal for residential and commercial applications requiring reliable circuit protection.
