Miniature Circuit Breaker 6kA 3 Pole 32A | C Curve | IP40 Rated by NHP
Miniature circuit breaker with 6kA breaking capacity and C curve trip—ideal for residential, commercial, and industrial applications. Built for safety and efficiency, with IP40 protection and 32A rated current.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP MOD6+ Miniature Circuit Breaker MCB 6kA 3 Pole 32A C Curve
Brand: NHP
SKU: MD6M332
Alternatively Known As: NHP Miniature Circuit Breaker, MCB 32A, 3 Pole Circuit Breaker
Technical Specifications
- Rated Current: 32 A
- Number of Poles: 3
- Trip Curve: C
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Voltage Type: AC
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-25 mm² (solid), 0.75-16 mm² (multi-wired)
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Operating Ambient Temperature: -25 to 70 °C
- Dimensions (H x L x W): 85mm x 75.8mm x 52.5mm
- Weight: 0.35 kg
Key Features
- 6kA short circuit breaking capacity.
- C curve trip characteristic suitable for general applications.
- IP40 rated for protection against solid objects.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
- Energy-efficient design contributes to reduced energy consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP MOD6+ Miniature Circuit Breaker MCB 6kA 3 Pole 32A C Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
