Miniature Circuit Breaker 8A 1Pole | 10kA B Curve | IP40 Rated by NHP
Miniature circuit breaker with 8A rated current and B curve trip—ideal for residential, commercial, and industrial applications. Built for safety and efficiency, with 10kA short circuit capacity and IP40 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley Miniature Circuit Breaker UL1077 10kA 1Pole 8A B Curve
Brand: NHP
SKU: 1492SPM1B080
Alternatively Known As: MCB, Miniature Circuit Breaker, Circuit Protection Device
Technical Specifications
- Rated Current: 8 A
- Number of Poles: 1
- Trip Curve: B
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Rated Short Circuit Breaking Capacity: 10kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-35 mm² (solid), 1-25 mm² (multi-wired)
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Dimensions (H x L x W): 80mm x 67mm x 17.5mm
- Weight: 0.12 kg
Key Features
- Rated current of 8A with a B curve trip characteristic.
- Short circuit breaking capacity of 10kA.
- IP40 rated for protection against solid objects.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, offices
- Commercial: Retail, hospitality, workspaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60947 for safety and performance standards.
Environmental Benefits
- Designed for energy efficiency and safety in electrical systems.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley Miniature Circuit Breaker UL1077 10kA 1Pole 8A B Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
Non-Returnable & Non-Cancellable
