Miniature Circuit Breaker DC 6kA 1Pole | 63A C Curve | Compact 18mm by NHP
Miniature circuit breaker with 63A C curve and 6kA breaking capacity—ideal for residential, commercial, and industrial applications. Built for safety, with compact 18mm design for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Miniature Circuit Breaker DC 6kA 1Pole 63A C Curve
Brand: NHP
SKU: DTCBDC163C
Alternatively Known As: Miniature Circuit Breaker, MCB, DC Circuit Breaker
Technical Specifications
- Rated Current: 63 A
- Number of Poles: 1
- Trip Curve: C
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-35 mm² (solid), 1-25 mm² (multi-wired)
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 6 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -25-70 °C
- Dimensions (H x L x W): 86mm x 76mm x 18mm
- Weight: 0.13 kg
Key Features
- C Curve trip characteristic for moderate inrush currents.
- Rated short circuit breaking capacity of 6 kA.
- Compact design with a width of 18mm.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
- Designed to enhance electrical safety and reduce fire hazards.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker DC 6kA 1Pole 63A C Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
