Miniature GP Relay 10A 2CO | 24VDC Coil | LED & Mech Indicator | Gold Contacts by NHP
Miniature GP relay with 24VDC coil and LED plus mechanical indicator—ideal for automation and control panels. Built for high electrical and mechanical life cycles, with easy plug-in connection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Finder 55 Series Miniature GP Relay 10A 2CO 24VDC Coil PB plus LED plus Mech Indi Gold Cont
Brand: NHP
SKU: 5532507424VDC
Alternatively Known As: Miniature Relay, GP Relay, 10A Relay, Finder Relay
Technical Specifications
- Nominal Current: 10 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage (UE AC): 400 V
- Number of Contacts: 2 (Change Over)
- Rated Switching Power at AC-1: 2500 VA
- Rated Switching Power at AC-15 (230 V): 500 VA
- Breaking Capacity at DC-1 (30 V): 10 A
- Breaking Capacity at DC-1 (110 V): 0.25 A
- Control Supply Voltage (US) at DC: 24 V
- Electrical Life at Un in Service: 200,000 cycles
- Mechanical Life: 50,000,000 cycles
- Operating Temperature: -40 to 85 °C
- Dimensions (H x L x W): 27.7mm x 36.7mm x 20.7mm
- Weight: 0.1 kg
Key Features
- General purpose relay with LED indication and mechanical indicator.
- Plug-in connection for easy installation.
- High electrical and mechanical life cycles.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Energy-efficient design contributes to reduced power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 55 Series Miniature GP Relay is available now for immediate purchase, ideal for industrial and commercial applications.
