Miniature PE Beam Sensor 10m Flush Design Ness

BRAND: Ness
SKU: 106-208
$342.60 List price: $456.70
+ −
30 Days Return Electricians Unlock Trade Access
Ness miniature PE beam sensor features a 10m range and flush design. Ideal for alarm systems.

Alternatively Known As: Ness 106-208, Takex Miniature PE Beam, Takex PB-10NS Near-Infrared Beam Sensor

Technical Specifications
  • Detection System: Near-infrared through-beam
  • Detection Range: Up to 10 m
  • Supply Voltage: 10–30 V DC, non-polarity
  • Current Consumption: 45 mA or less
  • Alarm Output: Dry-contact relay, N/O or N/C selectable, 30 V AC/DC at 0.3 A
  • Response Time: Detects beam interruption of 100 ms or longer
  • Operating Temperature: -25°C to +55°C, without condensation or icing
  • Sensor Dimensions: 15 mm diameter x 16 mm deep
  • Control Box Dimensions: 45 mm wide x 120 mm high x 29 mm deep
  • Construction: Clear PC resin sensor heads and white ABS resin control box
  • Mounting: Flush mounting plates supplied for sensor heads
  • Product Identification: Takex PB-10NS, supplied by Ness under SKU 106-208
  • Dimensions (H x L x W): 120mm x 45mm x 29mm
  • Weight: 0.335 kg
Key Features
  • Miniaturised single-beam design for discreet indoor protection
  • Flush-mounted sensor heads can be installed inconspicuously
  • Suitable for ATM machines, motor-driven shutters, windows, corridors and prestige applications
  • Built-in sensitivity adjustment for different protection distances
  • Sensor cable can be cut to the required installation length
  • N/O or N/C alarm output selection
  • Compact control box for installations where space is limited
Professional Installation Requirements
  • Installation should be performed by a qualified security or low-voltage technician. The transmitter and receiver must be correctly aligned, wired to a compatible alarm panel and commissioned in accordance with the manufacturer’s instructions and applicable intruder-alarm installation requirements.
Applications
  • Intruder alarm detection circuits
  • ATM and kiosk protection
  • Motor-driven shutter monitoring
  • Window and corridor beam protection
  • Discreet security installations in museums, galleries and showrooms
Standards & Compliance
  • AS/NZS 2201.1:2007 – relevant to the design, installation, commissioning and maintenance of intruder alarm systems incorporating detection devices; product-specific Australian certification was not stated
Environmental Benefits
  • Low-voltage operation with current consumption of 45 mA or less helps limit operating energy demand
  • Durable PC and ABS construction can support extended service life and reduce replacement waste
  • Compact hardwired design avoids the routine battery replacement associated with battery-powered sensors
Warranty Information

Ness states that Ness manufactured or supplied products are covered for 3 years from the date of purchase unless otherwise specified; confirm the warranty treatment for this Takex product with the supplying distributor.

Available Now

Available through Ness and authorised Australian security distributors; confirm current stock and lead time before ordering.
