Miniature Power Relay 12A 4CO | 6V AC Coil | Plug-In Connection by NHP
Miniature power relay with 12A nominal current and 4 change-over contacts—ideal for industrial automation and control panels. Built for reliable switching, with easy plug-in connection and energy-efficient operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Finder 56 Series Miniature Power Relay 12A 4CO 6V AC Coil
Brand: NHP
SKU: 56346VAC
Alternatively Known As: Miniature Power Relay, Switching Relay, Finder Relay
Technical Specifications
- Nominal Current: 12 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage: 400 V
- Rated Switching Power at AC 1: 3000 VA
- Rated Switching Power at AC 15 230 V: 700 VA
- Electrical Life: 100,000 cycles
- Mechanical Life: 20,000,000 cycles
- Operating Temperature: -40 to 70 °C
- Material of Contact: Silver nickel
- Dimensions (H x L x W): 27.7mm x 37.1mm x 40.8mm
- Weight: 0.1 kg
Key Features
- General purpose relay with 12A nominal current.
- 4 change-over contacts for versatile applications.
- Plug-in connection for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 56 Series Miniature Power Relay 12A 4CO 6V AC Coil is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable switching.
