MiniSight Photoelectric Sensor | 18mm Cylindrical | IP67 & NEMA 4X Rated | 43mm Sensing Distance | by Allen-Bradley
The MiniSight Photoelectric Sensor is designed for industrial automation, featuring a fixed focus diffuse sensing with a 43mm detection range. Ideal for manufacturing process control and material handling systems, this sensor offers IP67 and NEMA 4X ratings for dust and water resistance, ensuring reliable performance in harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor Type: Photoelectric, fixed focus diffuse
- Sensing Distance: 43 mm
- Light Source: Visible red
- Output Type: Power MOSFET 2
- Selectable AC/DC low or dark on
- Connection: 3 pin AC micro quick disconnect
- Pressure Resistance: 1200 PSI
- Ingress Protection: IP67
- NEMA Rating: 4X
- Dimensions (H x L x W): 43mm x 60mm x 18mm
- Weight: 0.1 kg
Key Features
- 18 mm cylindrical body with side through hole
- Fixed focus diffuse sensing
- Visible red light for easy alignment
- Manually adjustable settings
- Power MOSFET output type 2
- AC/DC low or dark on selectable
- 3 pin AC micro quick disconnect
- 43 mm sensing distance
- Standard on/off operation
- IP67 rated for dust and water resistance
- Withstands pressure up to 1200 PSI
- NEMA 4X rated for corrosion resistance
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper sensor alignment and electrical connections.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging machinery
- Material handling systems
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable IP67 and NEMA 4X ratings reduce replacement frequency and waste
- Energy-efficient sensor operation minimizes power consumption
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 42KLF2TCLG3 MiniSight Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
