Modular 1 Phase Control Relay | 5A, 2CO | 24-240V AC/DC | Clipsal
Modular 1 phase control relay with 5A current and 24-240V AC/DC voltage—ideal for industrial automation and commercial building management. Built for easy integration, with adjustable time delay and LED indicators.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Harmony Control Relays, Modular 1 phase current Control Relay, 5A, 2CO, 2…500mA, 24…240V AC DC
Brand: Clipsal
SKU: RM35JA31MW
Alternatively Known As: Modular Control Relay, Current Control Relay, 1 Phase Relay
Technical Specifications
- Rated current: 5A
- Control circuit voltage: 24...240V AC/DC
- Measurement range: 2...500mA AC/DC
- Electrical durability: 100,000 cycles
- Mechanical durability: 30,000,000 cycles
- IP Rating: IP20 (terminals), IP30 (casing)
- Operating temperature: -20...50 °C
- Relative humidity: 95% at 55 °C
- Maximum switching voltage: 250V AC
- Maximum power consumption: 3.5 VA AC
- Dimensions (H x L x W): 90mm x 70mm x 35mm
- Weight: 0.138 kg
Key Features
- Modular design for easy integration into existing systems.
- Adjustable time delay settings for operational flexibility.
- LED indicators for power and relay status.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, machinery control
- Commercial: Building management systems, HVAC control
Standards & Compliance
- Complies with IEC 60255 for safety and performance standards.
Environmental Benefits
- Green Premium product with packaging made from recycled materials.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Harmony Control Relay is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable current control.
