Modular Switch 1-Pole 40A | Red Toggle | IP20 Protection by Hager

BRAND: :hager
SKU: SBR140
$14.90 List price: $19.00
+ −
30 Days Return Delivery Options
1-pole modular switch with 40A rated current and IP20 protection—ideal for residential, commercial, and industrial circuit control. Built for easy identification with a red toggle, ensuring energy efficiency and compliance with AS/NZS 60947 standards.

Product Name/Title: 1-pole, 40A Modular Switch with Red Toggle

Brand: Hager

SKU: SBR140

Alternatively Known As: Modular Switch with Red Toggle, 40A 1-pole

Technical Specifications
  • Number of poles: 1
  • Rated current: 40 A
  • Breaking capacity 400 V AC23A: 846 A
  • Tightening torque: 2.80 Nm
  • Rated operational voltage Ue: 230 V
  • Rated insulation voltage Ui: 440 V
  • Rated impulse withstand voltage Uimp: 6000 V
  • Frequency: 50-60 Hz
  • Ingress Protection: IP20
  • Operating temperature: -20 to 70 °C
  • Cross-section flexible conductor: 2.5 - 16 mm²
  • Cross-section rigid conductor: 2.5 - 25 mm²
  • Electrical durability AC21: 5000 cycles
  • Dimensions (H x L x W): 83mm x 68mm x 17.50mm
  • Weight: 0.2 kg
Key Features
  • Rated current of 40A
  • 1-pole design for simplified installation
  • IP20 protection rating
  • Red toggle for easy identification
Professional Installation Requirements
  • Professional installation by a licensed electrician is recommended to ensure compliance and safety.
Applications
  • Residential: Circuit control in homes and apartments
  • Commercial: Electrical systems in offices and retail spaces
  • Industrial: Suitable for use in various industrial applications
Standards & Compliance
  • Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
  • Designed with energy efficiency in mind, contributing to reduced power usage.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The 1-pole, 40A Modular Switch with Red Toggle by Hager is available for immediate purchase, ideal for various electrical control applications.

SBR140 (SBR140, 121 Kb) [Download]

reach_declaration_SBR1409.pdf (reach_declaration_SBR1409.pdf, 103 Kb) [Download]

RoHS-declaration-SBR1409.pdf (RoHS-declaration-SBR1409.pdf, 33 Kb) [Download]

(SBR1_2_3_4XX_ISOLATINGSWITCHES.pdf, 98 Kb) [Download]

(NETHERLANDS_LICENCE_71_125608.pdf, 2,593 Kb) [Download]

NETHERLANDS_LICENCE_71_104407.pdf (NETHERLANDS_LICENCE_71_104407.pdf, 2,284 Kb) [Download]

(DECLARATION_25_1516_02_25.pdf, 991 Kb) [Download]
