Modular Switch 1-Pole 80A | Red Toggle | IP20 Rated by Hager

BRAND: :hager
SKU: SBR180
$17.10 List price: $21.90
+ −
30 Days Return Delivery Options
1-pole modular switch with 80A rating and red toggle—ideal for residential and commercial circuit isolation. Built for safety with IP20 rating, ensuring protection against solid objects.

Product Name/Title: 1-pole, 80A Modular Switch with Red Toggle

Brand: Hager

SKU: SBR180

Alternatively Known As: 80A 1P Modular Switch

Technical Specifications
  • Number of poles: 1P
  • Rated current: 80 A
  • Breaking capacity: 1354 A at 400 V AC23A
  • Nominal tightening torque: 3.60 Nm
  • Screw terminal connection
  • Rated operational voltage: 230 V AC
  • Rated insulation voltage: 440 V
  • Frequency: 50-60 Hz
  • Ingress Protection (IP) class: IP20
  • Height: 83 mm, Width: 17.50 mm, Depth: 68 mm
  • Number of mechanical operations: 40,000
  • Electrical durability in AC21: 2500 cycles
  • Dimensions (H x L x W): 83mm x 68mm x 17.50mm
  • Weight: 0.23 kg
Key Features
  • Modular switch design for circuit isolation
  • Red toggle for easy identification and operation
  • 1-Pole and 80A rated, suitable for various applications
  • IP20 rated for safety against solid objects
Professional Installation Requirements
  • Professional installation by a licensed electrician is recommended for compliance with safety standards and optimal performance.
Applications
  • Residential: Circuit isolation in homes, apartments
  • Commercial: Circuit control in retail and office spaces
  • Industrial: Equipment isolation in manufacturing units
Standards & Compliance
  • Compliant with IEC 60947-3 for switch disconnectors
  • Conforms to relevant AS/NZS electrical standards
Environmental Benefits
  • Efficient design minimizing power consumption
  • Durable material reducing replacement frequency, thereby minimizing environmental impact
Warranty Information

1-year standard warranty against manufacturing defects.

Available Now

This Hager Modular Switch with Red Toggle is available for immediate purchase, ideal for various residential and commercial circuit control needs.

SBR180 (SBR180, 121 Kb) [Download]

reach_declaration_SBR1809.pdf (reach_declaration_SBR1809.pdf, 103 Kb) [Download]

rohs_declaration_SBR1809.pdf (rohs_declaration_SBR1809.pdf, 104 Kb) [Download]

(SBR1_2_3_4XX_ISOLATINGSWITCHES.pdf, 98 Kb) [Download]

(NETHERLANDS_LICENCE_71_125608.pdf, 2,593 Kb) [Download]

(DECLARATION_25_1516_02_25.pdf, 991 Kb) [Download]
