Modular Switch 2-Pole 100A | Red Toggle | IP20 Rated by Hager
Modular switch with 2-pole design and 100A rating—ideal for residential, commercial, and industrial electrical systems. Built for robust applications, featuring a red toggle for clear operation and IP20 safety rating.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 2-pole, 100A Modular Switch with Red Toggle
Brand: Hager
SKU: SBR290
Alternatively Known As: Modular Switch with Red Toggle
Technical Specifications
- Architecture: Number of poles: 2, Neutral position: Without neutral, Type of pole: 2P
- Electric current: Rated current: 100 A, Breaking capacity 400 V AC23A: 1692 A, Rated conditional short-circuit current Icc with gl-gG fuses: 1.20 kA
- Installation, mounting: Nominal tightening torque: 3.60 - 3.60 Nm, Type of bottom connection for modular devices: Screw terminal
- Voltage: Rated operational voltage Ue: 400 - 400 V, Type voltage supply: AC, Rated insulation voltage Ui: 440 V, Rated impulse withstand voltage Uimp: 6000 V
- Capacity: Number of modules: 2
- Safety: Ingress Protection (IP) class: IP20
- Frequency: Frequency: 50 - 60 Hz
- Dimensions: Height: 83 mm, Width: 35 mm, Depth: 68 mm
- Equipment: Number of NO contacts: 2, Number of NC contacts: 0
- Use conditions: Operating temperature: -20 - 70 °C, Storage/transport temperature: -40 - 80 °C
- Connection: Cross-section flexible conductor: 6 - 35 mm², Cross-section rigid conductor: 6 - 50 mm²
- Endurance: Number of mechanical operations: 40000, Electrical durability at nominal load in AC21 in operating cycles: 2500, Electrical durability at nominal load in AC22 in operating cycles: 2500
- Power: Total power loss under IN: 11 W, Power loss per pole at In: 5.50 W
- Connectivity: Down connection alignment for modular devices: Aligned terminal, Top connection alignment for modular devices: Aligned terminal
- Dimensions (H x L x W): 83mm x 68mm x 35mm
- Weight: 0.2 kg
Key Features
- 2-pole design for enhanced electrical distribution
- Rated current of 100 A for robust applications
- Red toggle for clear operation indication
- Rated impulse withstand voltage of 6000 V for improved safety
- Ingress Protection class IP20
Professional Installation Requirements
- Professional installation by a certified electrician is advised for optimal safety and performance.
Applications
- Residential electrical circuits
- Commercial electrical systems
- Industrial settings requiring robust switching solutions
Standards & Compliance
- Conforms to the IEC 60947-3 standard for low-voltage switchgear
Environmental Benefits
- Designed for energy efficiency and reduced power consumption
Warranty Information
5 years warranty against manufacturing defects.
Available Now
The 2-pole, 100A Modular Switch with Red Toggle by Hager is available for immediate purchase, ideal for residential, commercial, and industrial installations.
