Modular Switch 3-Pole 40A | Red Toggle | IP20 Rated by Hager
3-pole modular switch with 40A rated current and red toggle—ideal for industrial, commercial, and residential electrical systems. Built for high endurance with IP20 protection and 60,000 mechanical operations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3-pole, 40A Modular Switch with Red Toggle
Brand: Hager
SKU: SBR340
Alternatively Known As: Hager Modular Switch
Technical Specifications
- Architecture: 3 poles
- Neutral position: Without neutral
- Rated current: 40 A
- Breaking capacity 400 V AC23A: 846 A
- Rated conditional short-circuit current Icc: 0.60 kA
- Rated short-circuit making capacity Icm: 0.84 kA at 415 V AC
- Rated operational voltage Ue: 400 V
- Rated insulation voltage Ui: 440 V
- Rated impulse withstand voltage Uimp: 6000 V
- Frequency: 50 - 60 Hz
- Nominal tightening torque: 2.80 Nm
- Ingress Protection (IP) class: IP20
- Cross-section flexible conductor: 2.5 - 16 mm²
- Cross-section rigid conductor: 2.5 - 25 mm²
- Dimensions (H x L x W): 83mm x 68mm x 52.50mm
- Weight: Not Specified kg
Key Features
- Rated current of 40A with a 3-pole configuration
- Red toggle for clear ON/OFF indication
- High electrical endurance with 60,000 mechanical operations
- IP20 rating for ingress protection
- Suitable for environments with operating temperatures of -20 to 70 °C
Professional Installation Requirements
- Professional installation by a qualified electrician is required.
Applications
- Industrial electrical panels
- Commercial power distribution
- Residential electrical systems
Standards & Compliance
- Complies with IEC 60947 standards
Environmental Benefits
- Long electrical durability reduces waste over time.
Warranty Information
5-year warranty against manufacturing defects.
Available Now
Available for immediate purchase, suitable for use in industrial, commercial, and residential power systems.
