Molded Case Circuit Breaker 125A H Frame | 100 kA Breaking Capacity | Fixed Thermal & Magnetic Trip | by Allen-Bradley
The Molded Case Circuit Breaker 125A H Frame is designed for robust electrical protection in industrial and commercial applications. With a 100 kA breaking capacity and fixed thermal/magnetic trip units, it ensures reliable performance and safety. Ideal for electrical distribution systems and motor control, this circuit breaker is built to enhance safety and reduce equipment damage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Current Rating: 125 A (H Frame)
- Breaking Capacity: 100 kA
- Trip Unit: Fixed thermal / fixed magnetic
- Poles: 3
- Current Range: 63 A
- Dimensions (H x L x W): 120mm x 75mm x 90mm
- Weight: 5 kg
Key Features
- 125 A H frame current rating
- 100 kA breaking capacity
- Fixed thermal and fixed magnetic trip units
- 3 poles configuration
- 63 A current range
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Industrial electrical distribution systems
- Commercial electrical panels
- Motor protection and control
- Power distribution in manufacturing plants
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of fire and equipment damage
- Durable design reduces need for frequent replacements, minimizing waste
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
Available for immediate purchase, ideal for industrial and commercial electrical protection applications.
