Molded Case Circuit Breaker 160A | Three-Pole Design | Box Terminal Connection | IEC60947 Compliant by Eaton
The NZM2-160-XKC molded case circuit breaker offers a robust three-pole design rated for up to 160A, ideal for industrial electrical panels and commercial switchgear. Built for safety and compliance, it features a box terminal connection and meets IEC60947 standards, ensuring reliable protection for copper cable systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Molded Case Circuit Breaker 160A | Three-Pole Design | Box Terminal Connection | IEC60947 Compliant by Eaton
Brand: Eaton
SKU: Y7-262240
Alternatively Known As: Eaton NZM2 160A circuit breaker, NZM2-160-XKC MCCB, Eaton Molded Case Breaker 160 Amp
Technical Specifications
- Amperage Rating: up to 160 A
- Number of Poles: Three-pole
- Terminal Capacity (Copper Strip): 2 segments of 9 mm x 0.8 mm to 10 segments of 16 mm x 0.8 mm or 8 segments of 15.5 mm x 0.8 mm (2x)
- Terminal Capacity (Stranded Cable): 10 mm² - 185 mm² (1x), 4 mm² - 70 mm² (2x), up to 95 mm² depending on cable manufacturer
- Certifications: IEC60947, CSA-C22.2 No. 5-09, UL489, CE marking
- Compliances: UL/CSA IEC RoHS conform
- Mechanical and thermal stability meet product standard requirements
- Dimensions (H x L x W): 184mm x 103mm x 105mm
- Weight: 0.243 kg
Key Features
- Molded case circuit breaker with box terminal connection
- Three-pole design suitable for up to 160 A
- Complies with IEC60947 and UL standards
- Suitable for copper cable with various terminal capacities
- Meets corrosion resistance and thermal stability requirements
Professional Installation Requirements
- Installation must be performed by a qualified electrician familiar with industrial switchgear and circuit breaker standards to ensure compliance and safety.
Applications
- Industrial electrical panels
- Commercial switchgear assemblies
- Electrical protection for three-pole copper cable systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Designed to enhance electrical safety and reduce risk of electrical faults
- Supports energy-efficient electrical system protection
Warranty Information
Warranty details available upon request from Eaton; typically includes coverage against manufacturing defects.
Available Now
The Eaton NZM2-160-XKC Molded Case Circuit Breaker is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
