Motor Circuit Breaker 22kW | 37-50A Adjustable Trip | 3-Pole Protection | by Clipsal
The Motor Circuit Breaker 22kW is designed for reliable motor protection, featuring adjustable thermal and magnetic trip settings for currents between 37-50A. Ideal for industrial applications such as pumps, HVAC systems, and manufacturing equipment, this breaker ensures safety with short-circuit and overload protection, all in a compact DIN rail mounting design.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Motor Circuit Breaker 22kW | 37-50A Adjustable Trip | 3-Pole Protection | by Clipsal
Brand: Clipsal
SKU: SCHGV3P50
Alternatively Known As: motor protection circuit breaker, motor starter breaker, GV3P50, 22kW motor breaker, Clipsal motor breaker
Technical Specifications
- Rated operational current: 37-50A
- Maximum motor power: 22kW (400V AC)
- Number of poles: 3
- Trip class: Adjustable thermal and magnetic
- Short-circuit breaking capacity: 100kA (400V AC)
- Mounting: DIN rail
- Operating voltage: up to 690V AC
- IP20 front protection
- Dimensions (H x L x W): 130mm x 120mm x 55mm
- Weight: 1.2 kg
Key Features
- Adjustable thermal and magnetic trip settings (37-50A)
- Rated for motors up to 22kW (400V AC)
- Three-pole protection
- Manual ON/OFF control with clear status indication
- Short-circuit and overload protection
- Compact DIN rail mounting design
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Industrial motor protection
- Pumps and compressors
- HVAC systems
- Conveyor systems
- Manufacturing equipment
Standards & Compliance
- Complies with AS/NZS 60947.4.1 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Prevents motor damage, reducing equipment waste
- Enhances energy efficiency by protecting motors from overload
- Long operational life reduces replacement frequency
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Motor Circuit Breaker 22kW 37-50A SCHGV3P50 is available for immediate purchase. Ideal for industrial motor protection and control applications.
