Trade Discount 33%
Motor Circuit Breaker 3P 17-23A | Thermal Magnetic | Toggle Handle by Clipsal
Motor circuit breaker with thermal-magnetic trip unit and 3P configuration—ideal for industrial and commercial motor protection. Built for reliability, with 23A current rating and easy toggle operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TeSys GV2, Motor circuit breaker, TeSys Deca,3P, 17-23A, thermal magnetic, screw clamp terminals,toggle handle
Brand: Clipsal
SKU: GV2RT21
Alternatively Known As: TeSys GV2 Circuit Breaker, Motor Protection Breaker, Thermal Magnetic Circuit Breaker
Technical Specifications
- Rated current: 23A
- Rated operational voltage: 690V AC 50/60Hz
- Trip unit technology: Thermal-magnetic
- Poles description: 3P
- Breaking capacity: 50kA Icu at 220/230V AC
- Mechanical durability: 100,000 cycles
- Electrical durability: 100,000 cycles for AC-3 at 415V
- Tightening torque: 1.7 N.m on screw clamp terminal
- Fire resistance: 960 °C conforming to IEC 60695-2-11
- Dimensions (H x L x W): 89mm x 78.5mm x 45mm
- Weight: 0.29 kg
Key Features
- Thermal-magnetic trip unit technology for reliable motor protection.
- Rated current of 23A and operational voltage of 690V AC.
- Mechanical and electrical durability of 100,000 cycles.
- Toggle control type for easy operation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor protection in various applications
- Commercial: Suitable for use in commercial electrical systems
Standards & Compliance
- Complies with EN/IEC 60947-2 and EN/IEC 60947-4-1 for safety and performance standards.
Environmental Benefits
- Packaging made with recycled cardboard and without single-use plastic.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal TeSys GV2 Motor Circuit Breaker is available now for immediate purchase. Ideal for industrial and commercial motor protection applications.
