Motor Circuit Breaker 3P 4-6.3A | Thermal Magnetic | High Breaking Capacity by Clipsal
Motor circuit breaker with 4-6.3A thermal-magnetic protection and high 100kA breaking capacity—ideal for industrial 3-phase motor applications. Built for durability with screw clamp terminals and push-button control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated current: 6.3A
- Rated operational voltage: 690V AC 50/60Hz
- Trip unit technology: thermal-magnetic
- Poles description: 3P
- Breaking capacity: 100kA Icu at 400V AC
- Mechanical durability: 100,000 cycles
- Electrical durability: 100,000 cycles for AC-3 at 415V
- Dimensions (H x L x W): 89mm x 78.5mm x 45mm
- Weight: 0.26 kg
Key Features
- Thermal-magnetic protection with a setting range of 4-6.3A.
- High breaking capacity of 100kA@400V.
- Start-stop control by push-button guaranteed for 100,000 cycles.
- Connection via screw clamp terminals.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: 3-phase motor applications
- General: Motor protection in various settings
Standards & Compliance
- Complies with IEC 60947-2 and other multi standards.
Environmental Benefits
- Green Premium compliant (RoHS/REACh).
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The TeSys GV2 Motor Circuit Breaker is available now for immediate purchase. Ideal for industrial motor protection applications.
