Motor Circuit Protector 32A | 690V | 50kA Breaking Capacity | IP2X by NHP

BRAND: NHP
SKU: 140MTD9NC32
$539.50 List price: $716.40
+
Motor circuit protector with 32A rated current and 50kA breaking capacity—ideal for industrial and commercial motor protection. Built for safety and reliability, with IP2X protection and turn handle control.

Product Name/Title: Allen-Bradley 140MT Motor Circuit Protector 32A

Brand: NHP

SKU: 140MTD9NC32

Alternatively Known As: Motor Circuit Breaker, Motor Protection Circuit Breaker, 140MTD9NC32

Technical Specifications
  • Rated permanent current: 32 A
  • Max rated operation voltage: 690 V
  • Rated operation power at AC 3, 400 V: 15 kW
  • Number of poles: 3
  • Max tightening torque: 2.5 Nm
  • Dimensions (H x L x W): 96.3mm x 93.7mm x 45mm
  • Weight: 0.41 kg
Key Features
  • Rated permanent current: 32 A
  • Magnetic switch-off technique
  • Rated short-circuit breaking capacity: 50 kA
  • Turn handle control element
  • IP2X degree of protection
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Motor protection in manufacturing and processing plants
  • Commercial: Equipment protection in commercial facilities
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
  • Enhances safety and reliability in electrical systems, reducing the risk of equipment failure.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 140MT Motor Circuit Protector 32A is available now for immediate purchase, ideal for industrial and commercial applications.

140MTD9NC32-AU-Motor-Circuit-Protector-Datasheet.pdf (140MTD9NC32-AU-Motor-Circuit-Protector-Datasheet.pdf, 220 Kb) [Download]
