Motor Protection Circuit Breaker 1.0-1.6A | 100kA Breaking Capacity | IP2X by NHP
Motor protection circuit breaker with adjustable 1.0 to 1.6A overload protection and 100kA breaking capacity—ideal for industrial and commercial applications. Built for reliable circuit protection, with IP2X rating and thermomagnetic switch-off technique.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S KT9 Motor Protection Circuit Breaker KTC940H Frame D 1.0 to 1.6A
Brand: NHP
SKU: KTC940H1P6A
Alternatively Known As: Motor Protection Breaker, Circuit Breaker, Thermal Magnetic Breaker
Technical Specifications
- Rated Permanent Current: 1.6 A
- Max Rated Operation Voltage: 690 V
- Rated Short Circuit Breaking Capacity: 100 kA
- Rated Operation Power at AC 3 400 V: 0.55 kW
- Type of Control Element: Turn handle
- Type of Electrical Connection: Screw connection
- Number of Poles: 3
- Degree of Protection: IP2X
- Max Tightening Torque: 2.5 Nm
- Dimensions (H x L x W): 96.3mm x 93.7mm x 45mm
- Weight: 0.39 kg
Key Features
- Thermomagnetic switch-off technique for reliable protection.
- Adjustable long-time overload protection from 1 to 1.6 A.
- High breaking capacity of 100 kA at 400 V AC.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor protection in various machinery and equipment
- Commercial: Electrical systems requiring reliable circuit protection
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Designed to enhance safety and reliability in electrical systems.
Warranty Information
Standard warranty applies.
Available Now
The S+S KT9 Motor Protection Circuit Breaker KTC940H is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable motor protection.
