Motor Protection Circuit Breaker 34-40A | Thermomagnetic | IP2X Safety | KTA9 40H by NHP
Motor protection circuit breaker with thermomagnetic switch-off and adjustable overload protection from 34 to 40A—ideal for industrial and commercial applications. Built for reliable circuit protection, with IP2X safety and screw connection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S KT9 Motor Protection Circuit Breaker KTA9 40H Frame D 34 to 40A
Brand: NHP
SKU: KTA940H40A
Alternatively Known As: Motor Protection Circuit Breaker, KTA9 40H, KT9 Circuit Breaker
Technical Specifications
- Rated Permanent Current: 40 A
- Switch Off Technique: Thermomagnetic
- Long Time Overload Protection Adjustment Range: 34-40 A
- Max Rated Operation Voltage: 690 V
- Rated Short Circuit Breaking Capacity: 50 kA at 400 V AC
- Rated Operation Power at AC 3: 20 kW
- Type of Control Element: Turn handle
- Type of Electrical Connection: Screw connection
- Number of Poles: 3
- Max Tightening Torque: 2.5 Nm
- Dimensions (H x L x W): 96.3mm x 93.7mm x 45mm
- Weight: 0.41 kg
Key Features
- Thermomagnetic switch-off technique for reliable protection.
- Adjustable long-time overload protection from 34 to 40 A.
- IP2X degree of protection ensuring safety against accidental contact.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor protection in various machinery and equipment
- Commercial: Electrical installations requiring reliable circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
- Efficient protection reduces the risk of electrical failures, contributing to energy conservation.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The S+S KT9 Motor Protection Circuit Breaker KTA9 40H Frame D 34 to 40A is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable motor protection.
