Motor Protection Circuit Breaker 4.0-6.3A | 100kA | IP2X by NHP
Motor protection circuit breaker with 4.0 to 6.3A adjustable overload protection and 100kA short circuit capacity—ideal for industrial and commercial applications. Built for reliable motor safety, with thermomagnetic switch-off and IP2X protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 140MT Motor Protection Circuit Breaker 4.0 to 6.3A
Brand: NHP
SKU: 140MTC3EB63
Alternatively Known As: Motor Protection Circuit Breaker, 140MT Circuit Breaker
Technical Specifications
- Rated Permanent Current: 6.3 A
- Max Rated Operation Voltage: 690 V
- Rated Short Circuit Breaking Capacity: 100 kA at 400 V AC
- Rated Operation Power at AC 3, 400 V: 2.2 kW
- Number of Poles: 3
- Degree of Protection: IP2X
- Max Tightening Torque: 2.5 Nm
- Type of Control Element: Turn handle
- Type of Electrical Connection: Screw connection
- Dimensions (H x L x W): 96.3mm x 83.4mm x 45mm
- Weight: 0.36 kg
Key Features
- Thermomagnetic switch-off technique for reliable protection.
- Adjustable long-time overload protection from 4A to 6.3A.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor protection in manufacturing and processing plants
- Commercial: Equipment protection in commercial facilities
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
- Enhances energy efficiency by protecting motors from overloads and faults.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 140MT Motor Protection Circuit Breaker 4.0 to 6.3A is available now for immediate purchase. Ideal for industrial and commercial applications.
