Motor Protection Circuit Breaker 6.3-10A | Thermomagnetic | IP2X Safety by NHP
Motor protection circuit breaker with thermomagnetic switch-off and adjustable overload protection from 6.3 to 10A—ideal for industrial and commercial applications. Built for reliable equipment safety, with IP2X protection against accidental contact.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S KT9 Motor Protection Circuit Breaker KTC940H Frame D 6.3 to 10A
Brand: NHP
SKU: KTC940H10A
Alternatively Known As: Motor Protection Circuit Breaker, KTC940H, KT9 Circuit Breaker
Technical Specifications
- Rated Permanent Current: 10 A
- Switch Off Technique: Thermomagnetic
- Long Time Overload Protection Adjustment Range: 6.3-10 A
- Max Rated Operation Voltage: 690 V
- Rated Short Circuit Breaking Capacity: 100 kA at 400 V AC
- Rated Operation Power at AC 3: 4 kW
- Type of Control Element: Turn handle
- Type of Electrical Connection: Screw connection
- Number of Poles: 3
- Max Tightening Torque: 2.5 Nm
- Dimensions (H x L x W): 96.3mm x 93.7mm x 45mm
- Weight: 0.39 kg
Key Features
- Thermomagnetic switch-off technique for reliable protection.
- Adjustable long-time overload protection from 6.3 to 10 A.
- IP2X degree of protection ensuring safety against accidental contact.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor protection in manufacturing and processing plants
- Commercial: Equipment protection in commercial buildings
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
- Efficient protection reduces energy waste and enhances equipment lifespan.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The S+S KT9 Motor Protection Circuit Breaker KTC940H Frame D 6.3 to 10A is available now for immediate purchase, ideal for industrial and commercial applications.
