Home/Electrical/Switchgear/Circuit Breakers/Moulded Case Circuit Breaker (MCCB)/Moulded Case Circuit Breaker 100A | 40kA Breaking Capacity | IP4X Safety | HNA101U by Hager

Trade Discount 22%

Moulded Case Circuit Breaker h3 x160 TM ADJ 4P4D N0-100% 100A 40kA CTC

Moulded Case Circuit Breaker 100A | 40kA Breaking Capacity | IP4X Safety | HNA101U by Hager

BRAND: :hager

SKU: HNA101U

$1,182.10 List price: $1,511.60

+ −

30 Days Return Delivery Options

Moulded case circuit breaker with 100A rated current and 40kA breaking capacity—ideal for industrial, commercial, and residential power distribution. Built for safety with IP4X protection and versatile four-pole design.

Description
Attachments

Product Name/Title: Moulded Case Circuit Breaker h3 x160 TM ADJ 4P4D N0-100% 100A 40kA CTC

Brand: Hager

SKU: HNA101U

Alternatively Known As: MCCB, Moulded Case Circuit Breaker, Circuit Breaker 100A

Technical Specifications

Rated ultimate short-circuit breaking capacity Icu under 400 V AC: 40 kA
Rated service breaking capacity Ics under 230 V AC: 40 kA
Rated operational voltage Ue: 220 - 415 V
Frequency: 50 - 60 Hz
Rated insulation voltage Ui: 690 V
Total power loss under IN: 35.70 W
Electric endurance: 1000 cycles
Mechanical operations: 4000 cycles
Connection type: Screw terminal
Flexible conductor cross-section: 4 - 70 mm²
Rigid conductor cross-section: 4 - 95 mm²
Dimensions (H x L x W): 130mm x 68mm x 100mm
Weight: 2.5 kg

Key Features

Rated current of 100A with a breaking capacity of 40kA.
Four poles for versatile applications.
IP4X ingress protection for enhanced safety.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Power distribution in factories and manufacturing plants
Commercial: Electrical systems in office buildings and retail spaces
Residential: Main electrical panels in homes

Standards & Compliance

Complies with AS/NZS 60947-2 for safety and performance standards.

Environmental Benefits

RoHS and REACH compliant, contributing to reduced environmental impact.

Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager Moulded Case Circuit Breaker 100A 40kA is available now for immediate purchase. Ideal for industrial, commercial, and residential applications.

HNA101U (HNA101U, 183 Kb) [Download]

reach_declaration_HNA101U11.pdf (reach_declaration_HNA101U11.pdf, 103 Kb) [Download]

rohs_declaration_HNA101U11.pdf (rohs_declaration_HNA101U11.pdf, 104 Kb) [Download]

(ID1_X160_H3_6LE001633AB_CO_WEB.pdf, 8,716 Kb) [Download]

(DECLARATION_25_1426_03_25.pdf, 431 Kb) [Download]

(DECLARATION_25_3174_03_25.pdf, 435 Kb) [Download]
