Allen-Bradley 140G MCCB R Frame 125kA 3P 2500A Moulded Case Switch Isolator

Moulded Case Circuit Breaker 2500A | 80kA Breaking Capacity | 3 Pole | R Frame by NHP

BRAND: NHP

SKU: 140GR12S3E25

$28,121.60 List price: $37,341.80

Free pick up (over 25 kg)

For delivery quote message

30 Days Return Delivery Options

Moulded case circuit breaker with 2500A rated current and 80kA breaking capacity—ideal for industrial and commercial power distribution. Built for enhanced circuit protection, with three poles and high efficiency.

Description
Attachments

Product Name/Title: Allen-Bradley 140G MCCB R Frame 125kA 3P 2500A Moulded Case Switch Isolator

Brand: NHP

SKU: 140GR12S3E25

Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker Isolator

Technical Specifications

Rated ultimate short circuit breaking capacity: 80 kA at 415 V, 50 Hz
Rated service short circuit breaking capacity: 60 kA at 415 V, 50 Hz
Rated insulation voltage: 1000 V
Rated frequency: 50-60 Hz
Power loss: 219 W
Rated impulse withstand voltage: 12 kV
Suitable for isolation: Yes
Maximum operating temperature: 75 °C
Storage temperature: -40 to 80 °C
Max altitude before derating: 2000 m
Dimensions (H x L x W): 382mm x 284.5mm x 428mm
Weight: 79 kg

Key Features

Rated current: 2500 A
Three poles for enhanced circuit protection
High short circuit breaking capacity of 80 kA

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Power distribution and protection in manufacturing facilities
Commercial: Electrical systems in large buildings and infrastructure

Standards & Compliance

Complies with AS/NZS 60950 for safety of IT and communication equipment.

Environmental Benefits

Designed for high efficiency, reducing energy loss and operational costs.

Warranty Information

Standard warranty terms apply, please check with the supplier.

Available Now

The Allen-Bradley 140G MCCB R Frame 125kA 3P 2500A Moulded Case Switch Isolator is available now for immediate purchase. Ideal for industrial and commercial applications.

Non-Returnable & Non-Cancellable

140GR12S3E25-AU-140G-MCCB-R-Frame-Datasheet.pdf (140GR12S3E25-AU-140G-MCCB-R-Frame-Datasheet.pdf, 261 Kb) [Download]
