Mountable Distribution Board 63A 3 Phase IP65 Grey Powersafe
Powersafe 63A 3-phase IP65 mountable distribution board with 2x32A and 4x15A switched outlets, RCD protected.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Mountable Distribution Board WMM-01 | 63A 3 Phase | IP65 Enclosure | 2 x 32A & 4 x 15A Outlets | by Powersafe
Brand: Powersafe
SKU: WMM-01
Alternatively Known As: mountable distribution board, portable power board, industrial switchboard, temporary power board, generator distribution board, Powersafe WMM-01
Technical Specifications
- Board Rating: 63A three phase 415V
- Main Isolation Switch: 63A 3 pole IP65
- Main MCB: 1 x 63A 3 pole 10kA
- Socket Outlets: 2 x 32A 415V 5 pin IP66 switched, 4 x 15A 240V IP66 auto switched
- Additional MCBs: 2 x 32A 3 pole 10kA
- RCDs: 1 x 63A 4 pole 30mA, 1 x 20A 2 pole RCD/MCB combo 10kA 30mA, 2 x 16A 2 pole RCD/MCB combo 10kA 30mA
- Breather drain included
- Optional lead fitting
- Continuous current draw: 25A three phase 415V (RDF 0.4)
- Thermal Management System available for full 63A constant load
- Dimensions (H x L x W): 770mm x 290mm x 420mm
- Weight: 20 kg
Key Features
- Heavy duty, easy to mount distribution board
- Multiple three-phase and single-phase outlets
- IP65 rated enclosure for dust and water protection
- 63A 3 pole main isolation switch
- 2 x 32A 415V 5 pin IP66 switched socket outlets
- 4 x 15A 240V IP66 auto switched outlets
- Comprehensive circuit protection with MCBs and RCDs
- Optional lead fitting available
- Breather drain for moisture management
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Generator manufacturers
- Serious workshop environments
- Industrial sites
- Construction sites
- Temporary power distribution for events
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3123 – Industrial Plugs and Socket-Outlets
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable construction reduces replacement frequency and waste
- IP65 enclosure minimizes risk of environmental contamination
- Supports safe and efficient temporary power distribution, reducing need for permanent infrastructure
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Powersafe WMM-01-STD Mountable Distribution Board is available for immediate purchase. Ideal for industrial, workshop, and temporary power distribution applications.
