Multi-point Housing for Flat Plug-in Sleeve | 2 Electrical Poles | IP20 Rated | Natural Color | @Pack of 5 | by Wurth
The Multi-point housing for flat plug-in sleeve is designed for secure electrical connections, featuring 2 electrical poles arranged in parallel and a contact gauge of 6.3 mm. Ideal for industrial and commercial equipment, this durable PA (Polyamide) housing supports wire cross sections from 0.5 to 6 mm², ensuring reliable performance in control panels and wiring assemblies.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Multi-point Housing for Flat Plug-in Sleeve | 2 Electrical Poles | IP20 Rated | Natural Color | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 55510021
Alternatively Known As: Flat Plug-in Sleeve Housing, Multi-point Connector Housing, Electrical Plug Housing 6.3x0.8mm
Technical Specifications
- Number of electrical poles: 2 PCS
- Arrangement of contacts: Both parallel
- Contact gauge: 6.3 mm
- Wire cross section: 0.5-6 mm²
- IP protection class: IP20
- Max. nominal voltage: 250 V AC/DC
- Max. current: 25 A
- Temperature range: -40 to 80 °C
- Material: PA - Polyamide
- Colour: Natural
- Dimensions (H x L x W): 10mm x 30mm x 20mm
- Weight: 0.05 kg
Key Features
- 2 electrical poles arranged in parallel
- Contact gauge of 6.3 mm
- Supports wire cross section from 0.5 to 6 mm²
- IP20 protection class
- Maximum nominal voltage of 250 V AC/DC
- Maximum current rating of 25 A
- Temperature range from -40 to 80 °C
- Made from durable PA (Polyamide) material
- Natural color housing
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards.
Applications
- Electrical connections in industrial and commercial equipment
- Use in control panels and wiring assemblies
- Suitable for electrical installations requiring secure plug-in connections
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable polyamide material reduces need for frequent replacements
- Supports efficient electrical connections reducing energy loss
Warranty Information
Standard manufacturer warranty applies.
Available Now
Wurth Multi-point Housing for flat plug-in sleeve 6.3 x 0.8 mm 5 PCS is available for immediate purchase, ideal for electrical wiring and connection applications.
