Multifunction Timer Relay | 8 Selectable Functions | 24–240V AC/DC | Compact DIN Rail Mount | @Pack of 1 | by Clipsal
The Multifunction Timer Relay is designed for versatile control in industrial automation and building management systems. With 8 selectable timing functions and a wide timing range from 0.05 seconds to 300 hours, it offers flexibility for various applications. Ideal for licensed electricians, this relay features LED status indicators and high switching capacity, ensuring reliable performance in HVAC, lighting control, and motor control systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Multifunction Timer Relay | 8 Selectable Functions | 24–240V AC/DC | Compact DIN Rail Mount | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHRE22R2MYMR
Alternatively Known As: Multifunction Timer Relay, Timer Relay, Time Delay Relay, Schneider RE22R2MYMR, Clipsal Timer Relay, Automation Timer Relay
Technical Specifications
- Supply voltage: 24–240V AC/DC
- Timing range: 0.05 seconds to 300 hours
- Functions: 8 selectable (e.g., delay on, interval, cyclic, etc.)
- Output contacts: 2 changeover (2CO), 8A at 250V AC
- Mounting: DIN rail (EN 60715)
- Status indication: LED for power and relay output
- Operating temperature: -20°C to +50°C
- IP20 protection (housing), IP40 (front panel)
- Dimensions (H x L x W): 90mm x 70mm x 17.5mm
- Weight: 0.12 kg
Key Features
- Multi-function timer relay with 8 selectable timing functions
- Wide timing range: 0.05 seconds to 300 hours
- Wide supply voltage: 24–240V AC/DC
- 2 changeover (2CO) relay outputs
- Compact 17.5mm DIN rail mounting
- LED status indicators for power and relay output
- High switching capacity: 8A at 250V AC
- Simple rotary switch setting for function and time range
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Industrial automation panels
- Building management systems
- Lighting control
- HVAC systems
- Pumping and motor control
- General electrical control circuits
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables energy-efficient automation by optimizing equipment run times
- Reduces unnecessary power consumption in control systems
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHRE22R2MYMR Multifunction Timer Relay is available for immediate purchase. Ideal for industrial automation, building management, and electrical control applications.
