MultiPulse Photoelectric Proximity Sensor | IP67 Rated | 30mm to 100mm Detection Zone | 10Hz Pulse Frequency | by SICK
The MultiPulse Photoelectric Proximity Sensor is designed for industrial automation, featuring a detection zone of 30mm to 100mm and a response time of ≤ 100 ms. With an IP67 rating for dust and water protection, this sensor operates efficiently in ambient temperatures from –40 °C to +60 °C, making it ideal for safety systems and machine monitoring applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Number of sensors: 2 pieces
- Detection zone: 30 mm to 100 mm
- Remission: 6% to 90%
- Pulse frequency: 10 Hz
- Response time: ≤ 100 ms
- Type of light: Visible red light
- Wavelength: 650 nm
- Light spot size (distance): Ø 7 mm at 50 mm
- Connection type: Connector M8, 3-pin
- Voltage supply: Via safety controller
- Enclosure rating: IP67 (EN 60529)
- Ambient operating temperature: –40 °C to +60 °C
- Dimensions (H x L x W): 50mm x 100mm x 20mm
- Weight: 0.2 kg
Key Features
- Natural protection due to the material
- Detection zone from 30 mm to 100 mm
- Visible red light with 650 nm wavelength
- Pulse frequency of 10 Hz
- Response time ≤ 100 ms
- IP67 rated enclosure for dust and water protection
- Connector M8, 3-pin connection type
- Operates in ambient temperatures from –40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper connection to safety controllers and compliance with electrical standards.
Applications
- Industrial automation for object detection
- Safety systems requiring natural protection sensors
- Machine monitoring and control
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements
- Energy-efficient sensor operation minimizes power consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy.
Available Now
The SICK SYS/SGD-W4100000002W4F MultiPulse Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and safety applications.
