MX 24V Shunt Release | Remote Tripping Function | 50/60Hz Compatibility | by Clipsal
The MX 24V Shunt Release is designed for remote tripping of compatible circuit breakers, operating on a 24V AC/DC supply at 50/60Hz. Ideal for electrical distribution panels and industrial automation systems, this compact device ensures reliable performance and safety in commercial and residential switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: MX 24V Shunt Release | Remote Tripping Function | 50/60Hz Compatibility | by Clipsal
Brand: Clipsal
SKU: SCHLV429384
Alternatively Known As: Shunt Trip, Circuit Breaker Shunt Release, Remote Trip Coil, MX Shunt Release, 24V Shunt Trip
Technical Specifications
- Rated Voltage: 24V AC/DC
- Frequency: 50/60Hz
- Function: Shunt release for remote tripping
- Compatibility: Suitable for use with compatible Clipsal and Schneider Electric circuit breakers
- Mounting: DIN rail or direct circuit breaker mounting
- Operating Temperature: -25°C to +70°C
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.15 kg
Key Features
- Enables remote tripping of compatible circuit breakers
- Operates on 24V AC/DC, 50/60Hz supply
- Compact and easy to install alongside circuit breakers
- Reliable performance for safety and control applications
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with Australian electrical safety standards.
Applications
- Remote tripping of circuit breakers in electrical distribution panels
- Industrial automation systems
- Commercial and residential switchboards
- Integration with emergency stop and safety systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Supports safe and efficient electrical system management, reducing risk of electrical hazards and enabling rapid response to faults.
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal MX 24V 50/60Hz Shunt Release (SCHLV429384) is available for immediate purchase. Ideal for integration in electrical distribution panels for remote tripping and enhanced safety.
