MX 48V Shunt Release | Remote Tripping | 50/60Hz Compatibility | Compact Design | @Pack of 1 | by Clipsal
The MX 48V Shunt Release is designed for remote tripping of compatible circuit breakers, operating at 48V AC/DC and 50/60Hz. Ideal for electrical distribution boards and industrial switchboards, this compact device ensures reliable and fast response for emergency shutdowns, enhancing safety in commercial circuit protection systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: MX 48V Shunt Release | Remote Tripping | 50/60Hz Compatibility | Compact Design | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLV429385
Alternatively Known As: Shunt Trip, Circuit Breaker Shunt Release, Remote Trip Coil, MX Shunt Release, Clipsal Shunt Trip
Technical Specifications
- Voltage: 48V AC/DC
- Frequency: 50/60Hz
- Function: Shunt release for remote tripping
- Compatibility: Suitable for use with compatible Clipsal and Schneider Electric circuit breakers
- Mounting: DIN rail or direct circuit breaker mounting
- Operating temperature: -25°C to +70°C
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.15 kg
Key Features
- Enables remote tripping of compatible circuit breakers
- Operates at 48V AC/DC, 50/60Hz
- Reliable and fast response for emergency shutdowns
- Compact design for easy integration into switchboards
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Electrical distribution boards
- Industrial switchboards
- Commercial circuit protection systems
- Remote tripping of circuit breakers
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Supports safe and efficient electrical system management, reducing risk of electrical fires and equipment damage.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal MX 48V 50/60Hz Shunt Release (SCHLV429385) is available for immediate purchase. Ideal for integration into electrical distribution boards and switchboards for enhanced safety and remote control.
