Navigator Security Keypad ArmorIP to Suit D8X4G Ness

BRAND: Ness
SKU: K-9308
$724.30 List price: $965.70
+ −
30 Days Return Electricians Unlock Trade Access
Ness Navigator security keypad features ArmorIP protocol support, to Suit D8X4G. Ideal for alarm system installs.

Alternatively Known As: Ness Navigator Keypad, Ness Navigator Touch Keypad, Ness 106-101 Navigator

Technical Specifications
  • Compatibility: Ness D8/D16XCEL 3G and 4G panels, D8x/D16x Rev 7 and later, and DPlus panels
  • Display: 3.5-inch colour LCD
  • Display Resolution: 320 x 240 pixels
  • User Interface: Touch-sensitive screen with on-screen numeric keypad
  • Operating Voltage: 12 VDC supplied by the control panel
  • Current Draw: Approximately 25 mA at 50% backlighting; 50 mA at 100% backlighting
  • Data Interface: Proprietary Ness security data bus
  • Maximum Keypads: Up to four Navigator keypads per compatible panel
  • Protocol Compatibility: Suitable for D8X4G systems using Ness ArmorIP reporting
  • Origin: Made in Australia
  • Dimensions (H x L x W): 86mm x 108mm x 15mm
  • Weight: 0.2 kg
Key Features
  • Touch screen interface for arming, disarming and alarm-system control
  • Plain-English user prompts and programmable zone names
  • Displays alarm events, zone status and system information
  • Controls programmable auxiliary outputs
  • Compatible with Ness D8X4G and related XCEL security panels
  • Supplied with keypad, wiring loom and user documentation
Professional Installation Requirements
  • Installation and commissioning should be performed by a suitably qualified security professional in accordance with the control-panel installation instructions and AS/NZS 2201.1:2007. Isolate power before connecting or servicing the keypad.
Applications
  • Residential intruder alarm systems
  • Commercial security alarm installations
  • Replacement or additional keypad for compatible Ness D8X4G systems
  • Security system installations requiring touch-screen user control
Standards & Compliance
  • Applicable system installation standard: AS/NZS 2201.1:2007, Intruder alarm systems — Client’s premises — Design, installation, commissioning and maintenance
Environmental Benefits
  • RoHS compliance supports reduced use of restricted hazardous substances in electronic components
  • Low-voltage operation and low standby current help minimise operating energy consumption
  • Durable keypad construction can extend service life and reduce replacement waste
Warranty Information

Ness manufactured or supplied products are covered by a 3-year warranty from the date of purchase, unless otherwise specified. Warranty is subject to Ness Corporation terms and conditions.

Available Now

Available through Ness Corporation and authorised Australian security and electrical distributors.
