Non-Contact Velocity Sensor | 0.1% Measurement Accuracy | IP65/IP67 Protection | by SICK
The Non-Contact Velocity Sensor NCV50B-11CCP100100 offers exceptional 0.1% measurement accuracy and robust IP65/IP67 protection, making it ideal for industrial motion monitoring and retrofit applications. With bidirectional movement detection and a Class 1 laser technology, this sensor ensures reliable performance while minimizing wear and tear, extending its lifespan.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measurement accuracy: 0.1%
- Repeatability: 0.05%
- Nominal measuring distance: 50 mm
- Possible static measuring distance: 30 to 100 mm
- Speed measuring range: 0 to 10 m/s
- Permissible acceleration: ≤ 30 m/s²
- Light source: 2 continuous beam lasers, 850 nm wavelength
- Laser class: 1 (IEC 60825-1:2014)
- Output frequency: ≤ 625 kHz
- Supply voltage: 12 V to 30 V
- Communication interface: TTL / HTL
- Connection type: Male connector, M12, 8-pin, A-coded
- Protection class: III according to DIN EN 61140
- Enclosure rating: IP65/IP67
- Operating temperature range: 0 °C to +45 °C
- Storage temperature range: -32 °C to +60 °C
- Resistance to shocks: 30 g, 6 ms
- Resistance to vibration: 20 g, 10 Hz to 2000 Hz
- Dimensions (H x L x W): 32.5mm x 95mm x 140mm
- Weight: 0.4 kg
Key Features
- Non-contact measurement using Class 1 laser technology
- High measurement accuracy with large mounting tolerances
- Bidirectional movement detection with start/stop capability
- Invisible infrared light source with 2 continuous beam lasers
- Robust aluminum housing with IP65/IP67 protection rating
- Short-circuit resistant outputs and reverse polarity protection
- Parameterization and diagnostic interface with digital input/output
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with laser safety and electrical wiring standards to ensure proper mounting and compliance with safety regulations.
Applications
- Motion monitoring on various surfaces and objects
- Retrofit installations requiring easy mounting
- End-customer applications with non-contact measurement needs
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Non-contact measurement reduces wear and tear, extending sensor lifespan
- Low power consumption under 8W enhances energy efficiency
- Robust design minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK NCV50B-11CCP100100 Non-Contact Velocity Sensor is available for immediate purchase, ideal for industrial motion monitoring and retrofit applications.
