NPN Proximity Sensor | IP67, IP68, IP69K Rated | 40mm Sensing Range | 100Hz Switching Frequency | by SICK
The NPN Proximity Sensor is designed for industrial automation, featuring a robust IP67, IP68, and IP69K rating for harsh environments. With a sensing range of 40mm and a switching frequency of 100Hz, it ensures reliable object detection in challenging conditions. Ideal for applications requiring precise sensing, this sensor is built to withstand shock and vibration, making it a dependable choice for various industrial settings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10 V pp
- Voltage drop: ≤ 2 V
- Time delay before availability: ≤ 200 ms
- Hysteresis: 3% to 15%
- Reproducibility: ≤ 6%
- Temperature drift of sensing range: ± 10%
- Continuous current Ia: ≤ 200 mA
- No load current: 12.5 mA
- Cable gland clamping area: M20 1.5
- Wire size: ≤ 2.5 mm²
- Protection class: II
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- Housing and sensing face material: Plastic, PA 66
- Switching output: NPN complementary
- Switching frequency: 100 Hz
- Enclosure rating: IP67, IP68, IP69K
- Dimensions (H x L x W): 40mm x 118mm x 40mm
- Weight: 0.1 kg
Key Features
- Standard design housing with plastic PA 66 material
- Non-flush installation type
- Sensing range of 40 mm with safe sensing range of 32.4 mm
- Switching frequency of 100 Hz with NPN complementary output
- Electrical wiring: DC 4-wire
- High protection rating: IP67, IP68, IP69K
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Short-circuit and power-up pulse protection included
- Wide ambient operating temperature range from –25 °C to +85 °C
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for object detection
- Harsh environment sensing with IP67, IP68, IP69K protection
- Difficult application conditions requiring reliable sensing
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and electronic waste
- Energy-efficient operation with low power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK IQ40-40NNPKK0S proximity sensor is available for immediate purchase, ideal for industrial automation and harsh environment sensing applications.
