NPN Proximity Sensor IQ40 Short-Body Design | 40mm Sensing Range | IP67/IP68/IP69K Rated | by SICK
The NPN Proximity Sensor IQ40 is designed for industrial automation, featuring a short-body housing and a sensing range of 40 mm. With a robust IP67/IP68/IP69K protection rating, it excels in harsh environments, ensuring reliable object detection. Built for demanding applications, this sensor offers a switching frequency of 100 Hz and is made from durable Plastic PA 66, making it a dependable choice for your automation needs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10 V pp
- Voltage drop: ≤ 2 V
- Time delay before availability: ≤ 200 ms
- Hysteresis: 3% to 15%
- Reproducibility: ≤ 6%
- Temperature drift of sensing range: ± 10%
- Continuous current Ia: ≤ 200 mA
- No load current: 12.5 mA
- Switching output: NPN complementary
- Switching frequency: 100 Hz
- Connection type: Male connector M12, 4-pin
- Protection class: II
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- Ambient operating temperature: –25 °C to +85 °C
- Storage temperature: –40 °C to +85 °C
- Housing material: Plastic PA 66
- Sensing face material: Plastic PA 66
- Tightening torque max: 1.8 Nm
- Short-circuit and power-up pulse protection included
- Dimensions (H x L x W): 40mm x 66mm x 40mm
- Weight: 0.1 kg
Key Features
- Short-body housing design
- Non-flush installation type
- Sensing range of 40 mm with safe sensing range of 32.4 mm
- Switching frequency of 100 Hz
- NPN complementary switching output
- DC 4-wire electrical wiring
- Male connector M12, 4-pin connection
- High protection rating: IP67, IP68, IP69K
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Wide ambient operating temperature from –25 °C to +85 °C
- Short-circuit and power-up pulse protection included
- Housing and sensing face made of durable Plastic PA 66
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure correct mounting and electrical connection according to manufacturer guidelines.
Applications
- Industrial automation for object detection
- Harsh environment sensing with IP67, IP68, IP69K protection
- Difficult application conditions requiring reliable sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Energy-efficient operation with low power consumption
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK IQ40-40NNPKC0K proximity sensor is available for immediate purchase, ideal for industrial automation and harsh environment sensing applications.
