NSW Meter Box Lid Only Stainless Steel Bovara
Bovara stainless steel replacement lid suits the SMB600L.SS NSW standard meter box. Ideal for coastal and corrosive environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Stainless Steel Meter Box Lid, NSW Standard Meter Box Door, Replacement Meter Enclosure Lid
Technical Specifications
- Product Type: Replacement meter box lid only
- Compatible Enclosure: Bovara SMB600L.SS NSW standard meter box
- Material: 1.2 mm 316 stainless steel
- Finish: Stainless steel 2B finish
- Hinges: Fitted
- Lid Style: Top-opening hinged lid
- Locking Provision: Padlock hole up to 12 mm
- Enclosure Rating: IP23 when fitted to the compatible meter box
- Dimensions (H x L x W): 600mm x 600mm x 20mm
- Weight: 3.5 kg
Key Features
- Direct replacement lid for the Bovara SMB600L.SS meter box
- 316 stainless steel construction for enhanced corrosion resistance
- Suitable for coastal and corrosive environments
- Supplied with hinges fitted
- Maintains the compatible enclosure's top-opening and padlockable design
- Replacement component supplied without the complete meter box enclosure
Professional Installation Requirements
- Replacement should be carried out by a licensed electrician or suitably qualified electrical contractor where the meter box contains live electrical equipment. Confirm isolation, correct hinge alignment, earthing continuity and compliance with current NSW Service and Installation Rules before returning the enclosure to service.
Applications
- Replacement of damaged or corroded lids on Bovara SMB600L.SS meter boxes
- Residential electricity meter installations in New South Wales
- Commercial and light-industrial metering enclosures
- Metering enclosures installed in coastal or high-corrosion environments
Standards & Compliance
- Designed for use with Bovara meter box assemblies specified for the NSW Service Installation Rules
- Compatible enclosure listed with AS/NZS 61439.1:2016 requirements
- Installation must comply with AS/NZS 3000 and applicable NSW Service Installation Rules
Environmental Benefits
- 316 stainless steel provides extended service life in coastal and corrosive environments, reducing replacement waste
- Stainless steel is highly recyclable at the end of its service life
- Replacing the lid can extend the usable life of the existing meter box and reduce material consumption
Warranty Information
No specific Bovara warranty period was located for this replacement lid. Warranty claims should be confirmed with Bovara or the supplying distributor, and Australian Consumer Law guarantees apply where applicable.
Available Now
Available through authorised Bovara distributors in Australia.
