NSX400N Circuit Breaker | 50kA Breaking Capacity | 3 Pole 400A | Compact Design | @Pack of 1 | by Clipsal
The NSX400N Circuit Breaker is engineered for high-performance electrical distribution, featuring a robust 50kA breaking capacity at 415V AC and a rated current of 400A. Ideal for commercial and industrial applications, this molded case circuit breaker ensures advanced protection against overloads and short circuits, making it perfect for main switchboards and large infrastructure projects.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NSX400N Circuit Breaker | 50kA Breaking Capacity | 3 Pole 400A | Compact Design | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHC40N32D400
Alternatively Known As: NSX400N Circuit Breaker, 400A MCCB, 3 Pole 50kA Breaker, Schneider NSX400N, SCHC40N32D400
Technical Specifications
- Rated current: 400A
- Breaking capacity: 50kA at 415V AC
- Number of poles: 3
- Type: Molded Case Circuit Breaker (MCCB)
- Operating voltage: 415V AC
- Trip unit: Thermal-magnetic
- Mounting: Fixed
- Standards: IEC 60947-2 compliant
- Dimensions (H x L x W): 255mm x 110mm x 140mm
- Weight: 7.5 kg
Key Features
- High breaking capacity of 50kA at 415V AC
- 3 pole, 3 direct connection (3P3D) configuration
- Rated current: 400A
- Compact NSX frame for space-saving installation
- Advanced protection against overloads and short circuits
- Robust and reliable performance for demanding environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution systems
- Main switchboards and sub-distribution boards
- Protection of circuits against overloads and short circuits
- Suitable for large buildings, factories, and infrastructure projects
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Designed for long operational life, reducing replacement frequency and waste
- High efficiency reduces energy losses in electrical distribution
- Compliant with RoHS for reduced hazardous substances
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal NSX400N 50kA AC 3P3D 400A Circuit Breaker (SCHC40N32D400) is available for immediate purchase. Ideal for commercial and industrial electrical distribution systems.
