Nylon Cable Bush 45mm | Black Nylon Material | Self-Locking Installation | Cable Protection by Cabac
The Cabac Nylon Bush 45mm is a durable cable protection grommet designed to prevent damage from sharp edges in panel holes. Easy to install with self-locking teeth, it ensures smooth cable passage and is compatible with a range of nylon plugs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Nylon Bush 45mm
Brand: Cabac
SKU: NSB45
Alternatively Known As: Nylon Cable Grommet, Cable Bush, Panel Hole Grommet, Cable Protection Bushing
Technical Specifications
- Material: Nylon 66 UL, 94 V-2
- Colour: Black
- Chassis Thickness Compatibility: 0.8-3.2mm
- Hole Size (A): 43.6mm
- Inner Diameter (B): 35.4mm
- Outer Diameter (C): 47.8mm
- Height (L): 11.6mm
- Dimensions (H x L x W): 11.6mm x 47.8mm x 47.8mm
- Weight: 0.01 kg
Key Features
- Quick and simple solution to protect cables from sharp edges in panel holes
- Snaps into place with self-locking teeth for secure installation
- Available in a range of sizes
- Compatible with Cabac nylon plugs
- Creates a smooth surface to prevent cuts and abrasions on cables
Professional Installation Requirements
- Installation is straightforward and can be performed by qualified electricians or trained personnel to ensure proper fit and cable protection.
Applications
- Protecting cables passing through panel holes in electrical and electronic installations
- Used in cable and wire management systems to prevent cable damage
- Suitable for new installations and retrofitting existing panel holes
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable nylon material reduces the need for frequent replacements
- Protects cables, reducing electronic waste from damaged wiring
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac Nylon Bush 45mm is available for immediate purchase. Ideal for protecting cables in electrical panels and wire management systems.
