Off Delay Timer Relay | Adjustable Timing Range | DIN Rail Mounting | LED Status Indicators | @Pack of 1 | by Clipsal
The Off Delay Timer Relay is designed for precise timing control in industrial automation and lighting systems. With an adjustable timing range from 0.1 seconds to 100 hours and a multi-voltage input of 24-240V AC/DC, it’s perfect for HVAC systems and machinery requiring timed off delay. Featuring DIN rail mounting for easy installation and LED indicators for power and relay state, this timer enhances energy efficiency and operational reliability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Off Delay Timer Relay | Adjustable Timing Range | DIN Rail Mounting | LED Status Indicators | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHRE22R2CMR
Alternatively Known As: Time Delay Relay, Off Delay Timer Relay, Industrial Timer Relay, Clipsal Timer Relay, SCHRE22R2CMR
Technical Specifications
- Function: Off-delay timer relay
- Timing range: 0.1 seconds to 100 hours (adjustable)
- Supply voltage: 24-240V AC/DC
- Contact configuration: 2 changeover (DPDT) contacts
- Contact rating: 8A at 250V AC
- Mounting: DIN rail
- Status indication: LED for power and relay state
- Operating temperature: -20°C to +60°C
- Dimensions (H x L x W): 78mm x 100mm x 22.5mm
- Weight: 0.15 kg
Key Features
- Adjustable off-delay timer relay
- DIN rail mounting for easy installation
- Wide timing range: 0.1 seconds to 100 hours
- Multi-voltage input: 24-240V AC/DC
- 2 changeover (DPDT) contacts for versatile control
- LED status indicators for power and relay state
- Compact design for space-saving installation
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with Australian electrical standards and safe operation.
Applications
- Industrial automation panels
- Lighting control systems
- HVAC systems
- Pumping stations
- Machinery requiring timed off delay
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances energy efficiency by automating power-off cycles
- Reduces unnecessary equipment operation, lowering energy consumption
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal OFF DELAY TIMER SCHRE22R2CMR is available for immediate purchase. Ideal for industrial automation, lighting control, and machinery requiring precise off-delay timing.
