Opal 1200 1200VA 600W Line Interactive UPS AVR Chase Power

BRAND: Chase Power
SKU: CP2323
$320.80 List price: $481.30
+ −
30 Days Return Electricians Unlock Trade Access
Chase Power Opal 1200 line interactive UPS 1200VA/600W AVR tower. Backup for workstations, NAS and small servers.

Alternatively Known As: Opal 1200 UPS, 1200VA Line Interactive UPS, 600W AVR UPS, Uninterruptible Power Supply

Technical Specifications
  • UPS Topology: Line interactive
  • Capacity: 1200VA / 600W
  • Input Voltage: 230VAC
  • Input Voltage Range: 170-280VAC
  • Input Frequency Range: 45-55Hz or 55-65Hz
  • Output Voltage: 230VAC
  • Output Waveform: Modified sine wave
  • Output Power Factor: 0.5
  • Line Mode Voltage Regulation: ±15%
  • Battery Mode Voltage Regulation: ±10%
  • Battery Mode Frequency Regulation: ±1Hz
  • Transfer Time: Typical 4-8ms
  • Line Mode Efficiency: 95%
  • AVR Mode Efficiency: 88%
  • Battery Mode Efficiency: 60%
  • Battery Configuration: 2 x 12V 7Ah sealed lead-acid batteries
  • Rated Battery Voltage: 24VDC
  • Recharge Time: 2-6 hours to 90%
  • Outlets: 4 Australian outlets
  • Communication Interface: HID-compliant USB
  • Surge Protection: RJ11 phone/modem protection
  • Alarm Indicators: LCD display with audible battery, overload and fault alarms
  • Operating Humidity: 0-90% RH, non-condensing
  • Operating Temperature: 0°C to 40°C
  • Noise Level: Less than 45dB
  • Input Connection: Fixed 10A power cable
  • Monitoring Software: WinPower compatible
  • Dimensions (H x L x W): 195mm x 364mm x 139mm
  • Weight: 8.9 kg
Key Features
  • Line interactive power protection with built-in boost and buck automatic voltage regulation
  • 1200VA/600W capacity for computers, networking equipment, NAS devices, security systems and small business equipment
  • Four Australian output sockets and fixed 10A input power cable
  • HID-compliant USB interface supports Windows, macOS and Linux power management
  • Supports equipment with active power factor correction switching power supplies
  • LCD status display with audible operating, low-battery, overload and fault alarms
  • DC cold-start function enables operation without mains power
  • Automatic restart when mains power returns
  • User-replaceable battery design
  • Discharge, overcharge and overload protection
  • RJ11 phone/modem surge protection
  • Supplied with USB cable, user manual and downloadable monitoring software
Professional Installation Requirements
  • No specialist installation is normally required for this portable plug-in UPS. Connect it to a suitable earthed 10A Australian power outlet and follow the manufacturer's operating and battery replacement instructions. Any fixed electrical work must be completed by a licensed electrical worker in accordance with applicable Australian requirements.
Applications
  • Workstations and desktop computers
  • NAS and network-attached storage systems
  • Small servers and network equipment
  • Security and surveillance systems
  • Point-of-sale and EFTPOS equipment
  • Hi-fi and sensitive electronic equipment
  • Home and small business power backup
Standards & Compliance
  • Relevant UPS safety standard: AS 62040.1; confirm the specific model's current certification and Regulatory Compliance Mark documentation with the supplier
  • AS/NZS 3820 may apply as part of Australian electrical equipment safety requirements
  • Installation and any fixed wiring must follow AS/NZS 3000 where applicable
Environmental Benefits
  • User-replaceable batteries can extend the service life of the UPS and reduce whole-unit replacement waste
  • 95% line-mode efficiency can reduce operating energy losses compared with less efficient backup systems
  • Replaceable sealed lead-acid batteries should be recovered and recycled through an appropriate battery recycling channel
  • Automatic voltage regulation can help protect connected equipment and reduce premature equipment replacement
Warranty Information

Chase Power publishes a manufacturer warranty commitment for its UPS range, but a specific warranty duration for the Opal 1200 was not stated in the available product literature. Confirm the applicable warranty period and battery coverage with Chase Power or the authorised Australian distributor.

Available Now

Available through Chase Power and authorised Australian distributors, subject to current distributor stock.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
