Opal 650 650VA 360W Line Interactive UPS AVR Chase Power

BRAND: Chase Power
SKU: CP2321
$165.00 List price: $247.50
+ −
30 Days Return Electricians Unlock Trade Access
Chase Power Opal 650 line interactive UPS 650VA/360W AVR tower. Entry-level backup for home office PCs and modems.

Alternatively Known As: Opal 650 UPS, 650VA AVR UPS, Line Interactive UPS, Home Office UPS

Technical Specifications
  • Capacity: 650VA / 360W
  • Topology: Line interactive
  • Input Voltage: 230VAC
  • Input Voltage Range: 170–280VAC
  • Input Frequency Range: 45–55Hz / 55–65Hz
  • Output Voltage: 230VAC
  • Output Voltage Regulation: ±15% line mode; ±10% battery mode
  • Output Frequency: 50Hz
  • Battery Frequency Regulation: ±1Hz
  • Transfer Time: Typical 2–6ms
  • Output Waveform: Modified sine wave
  • Output Power Factor: 0.55
  • Efficiency: 95% line mode; 88% AVR mode; 60% battery mode
  • Battery: 12V/7Ah × 1
  • Rated Battery Voltage: 12VDC
  • Recharge Time: 2–6 hours to 90%
  • Charging Current: 1A
  • Outlets: 2 × Australian outlets
  • Interface: HID-compliant USB
  • Surge Protection: RJ11 phone/modem line protection
  • Alarm: Audible battery, low-battery, overload and fault indicators
  • Operating Environment: 0°C to 40°C; 0–90% RH non-condensing
  • Noise Level: Less than 40dB
  • Dimensions (H x L x W): 143mm x 290mm x 100mm
  • Weight: 4.4 kg
Key Features
  • Automatic voltage regulation with boost and buck AVR
  • USB interface supports power management and automatic shutdown on Windows, macOS and Linux
  • Supports equipment using active power factor correction power supplies
  • Built-in DC cold-start function
  • Automatic restart when mains power resumes
  • User-replaceable battery design
  • Discharge, overcharge and overload protection
  • Graphic LCD display
  • Built-in Ethernet/phone line protection
  • Supplied with fixed 10A input cable, USB cable and user manual
  • Manufacturer-listed dimensions and weight are 290 × 100 × 143mm and 4.4kg. ([chasepower.com.au](https://chasepower.com.au/chasepowerups/line-interactive-ups/opal-650/))
Applications
  • Home office computers and monitors
  • Modems, routers and networking equipment
  • Small business computers
  • Security systems
  • Hi-fi equipment
  • Eftpos machines and POS stations
Standards & Compliance
  • AS 62040.1:2019 is the applicable Australian safety standard for pluggable UPS equipment; product-specific certification was not stated in the available manufacturer documentation. ([eess.gov.au](https://www.eess.gov.au/wp-content/uploads/2020/07/20-006-General-guidance-Standards-for-portable-UPS-devices-1.pdf?utm_source=openai))
Environmental Benefits
  • User-replaceable battery design can extend the service life of the UPS and reduce whole-unit replacement waste
  • Automatic voltage regulation can help protect connected equipment from voltage fluctuations, potentially reducing premature equipment replacement
  • Lead-acid batteries should be returned through an approved battery-recycling or hazardous-waste collection programme at end of life
Warranty Information

Chase Power states that its UPS range is supplied with a warranty intended to match or exceed competing brands, but a specific warranty duration for the Opal 650 was not published in the available manufacturer documentation. ([chasepower.com.au](https://chasepower.com.au/wp-content/uploads/Chase_Power_UPS_Catalogue.pdf?utm_source=openai))

Available Now

Available through Chase Power and authorised Australian electrical and power-quality distributors.
