Opal 850 850VA 480W Line Interactive UPS AVR Chase Power
Chase Power Opal 850 line interactive UPS 850VA/480W AVR tower. Battery backup for home office PCs, NAS and networking.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Opal 850 AVR UPS, 850VA Uninterruptible Power Supply, Line Interactive UPS with AVR
Technical Specifications
- UPS Technology: Line interactive
- Capacity: 850VA / 480W
- Nominal Voltage: 230VAC
- Input Voltage Range: 170–280VAC
- Input Frequency Range: 45–55Hz / 55–65Hz
- Output Voltage: 230VAC
- Output Waveform: Modified sine wave
- Output Power Factor: 0.56
- Voltage Regulation in Battery Mode: ±10%
- Frequency Regulation in Battery Mode: ±1Hz
- Transfer Time: Typically 2–6ms
- Battery: 12VDC 9Ah sealed lead-acid battery, 1 unit
- Recharge Time: 2–6 hours to 90% capacity
- Outlets: 2 Australian outlets
- Management Interface: USB
- Surge Protection: RJ11 phone/modem line protection
- Display: LCD display
- Operating Environment: 0–40°C, 0–90% RH non-condensing
- Noise Level: Less than 40dB
- Input Connection: Fixed 10A power cable
- Dimensions (H x L x W): 143mm x 290mm x 100mm
- Weight: 5.2 kg
Key Features
- Automatic voltage regulation with boost and buck operation
- Provides battery backup for computers, NAS devices, networking equipment and other small electronic loads
- HID-compliant USB interface supports automatic power management and shutdown on Windows, Mac and Linux systems
- Supports equipment with active power factor correction switching power supplies
- DC cold-start function enables operation without mains power present
- Automatic restart when mains power is restored
- User-replaceable internal battery
- LCD status display
- Discharge, overcharge and overload protection
- Built-in RJ11 phone/modem surge protection
Professional Installation Requirements
- No specialist installation is normally required for this plug-in UPS. Connect to a suitable Australian 10A outlet and follow the manufacturer's operating and battery-safety instructions. Any fixed electrical alteration or building wiring work must be completed by a licensed electrician in accordance with applicable wiring requirements.
Applications
- Home office computers and peripherals
- Small business workstations
- NAS and network-attached storage equipment
- Routers, switches and networking equipment
- Security systems
- Hi-fi and audio-visual equipment
- Eftpos and point-of-sale terminals
Standards & Compliance
- AS 62040.1:2019 — applicable Australian UPS safety standard for low-voltage UPS equipment; product-specific conformity should be confirmed from the supplier's compliance documentation
- AS/NZS 3000:2018 — relevant to any fixed electrical installation or wiring work associated with the UPS
Environmental Benefits
- User-replaceable battery design can extend the service life of the UPS and reduce whole-unit replacement waste
- The sealed lead-acid battery is replaceable and should be recycled through an appropriate battery recycling programme at end of life
- Automatic voltage regulation can help protect connected equipment from voltage disturbances and reduce premature equipment replacement
Warranty Information
Chase Power states that its UPS range is supplied with a warranty intended to match or exceed comparable brands, but the published Opal 850 information does not specify a warranty period. Confirm the applicable warranty term and battery coverage with Chase Power or the authorised distributor before purchase.
Available Now
Available through Chase Power and authorised Australian distributors, subject to current distributor stock.
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
