Optical Fork Sensor WF2-B4210 | Infrared Detection | IP65 Rated | 10 kHz Switching Frequency | by SICK
The Optical Fork Sensor WF2-B4210 is designed for precise label detection in industrial automation, featuring an infrared LED light source and a high switching frequency of 10 kHz. With an IP65 rated aluminum housing, it ensures durability and reliability in manufacturing lines and packaging systems, making it ideal for various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 40 mA
- Switching frequency: 10 kHz
- Response time: ≤ 30 µs
- Output function: Light/dark switching, adjustable via reverse polarity
- Switching output: PNP/NPN with max output current 100 mA
- Enclosure rating: IP65
- Housing material: Aluminum
- Connection type: Male connector M8, 4-pin
- Ambient operating temperature: –20 °C to +60 °C
- Ambient storage temperature: –20 °C to +80 °C
- Ambient light immunity: ≤ 10,000 lx
- Shock load: According to EN 60068-2-27
- Protection class: III
- Dimensions (H x L x W): 37mm x 80mm x 12mm
- Weight: 0.1 kg
Key Features
- Optical detection principle with infrared LED light source
- Fork width of 2 mm and fork depth of 40 mm for precise detection
- Light/dark switching output adjustable via reverse polarity
- High switching frequency of 10 kHz and fast response time ≤ 30 µs
- IP65 rated aluminum housing for robust industrial use
- Short-circuit protected output with interference pulse suppression
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for label detection
- Optical object detection in manufacturing lines
- Packaging and material handling systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Low power consumption with 10 V DC to 30 V DC supply voltage
- Durable aluminum housing reduces waste through long product life
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WF2-B4210 Optical Fork Sensor is available for immediate purchase, ideal for industrial automation and label detection applications.
