Optical Fork Sensor WFS3-40B41CA00 | Infrared Detection | IP65 Rated | 15 kHz Switching Frequency | by SICK
The Optical Fork Sensor WFS3-40B41CA00 is designed for precise label detection in packaging and printing industries. With an infrared detection principle, a high switching frequency of 15 kHz, and an IP65-rated robust housing, it ensures reliable performance in industrial automation. Ideal for applications requiring accurate object detection, this sensor features multiple teach-in modes and a wide operating temperature range from -20 °C to +60 °C.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching frequency: 15 kHz
- Response time: ≤ 46 µs
- Switching output: Push-pull PNP/NPN
- Output current max: 100 mA
- Enclosure rating: IP65
- Housing material: Glass-fiber reinforced PA
- Connection type: Male M8, 4-pin connector
- Ambient operating temperature: -20 °C to +60 °C
- Ambient light immunity: ≤ 10,000 lx
- Safety parameters: MTTFD 97 years, DCavg 0%
- Dimensions (H x L x W): 25mm x 64.3mm x 10mm
- Weight: 0.1 kg
Key Features
- Optical detection principle with infrared LED light source
- Fork width of 3 mm and fork depth of 42 mm for precise label detection
- Minimum detectable object size of 2 mm gap between labels
- Multiple teach-in modes including 1-point, 2-point, and dynamic
- IO-Link V1.1 communication interface for advanced data exchange
- High switching frequency of 15 kHz and fast response time ≤ 46 µs
- Push-pull PNP/NPN switching output with light/dark switching mode
- Robust PA glass-fiber reinforced housing with IP65 rating
- Wide ambient operating temperature range from -20 °C to +60 °C
- Protection against reverse polarity, short-circuit, and interference pulses
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper setup and compliance with electrical standards.
Applications
- Label detection in packaging and printing industries
- Object detection in automation and manufacturing processes
- Industrial automation requiring precise optical sensing
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw reduces energy usage
- Durable design minimizes waste and replacement frequency
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK WFS3-40B41CA00 Optical Fork Sensor is available for immediate purchase, ideal for industrial automation and label detection applications.
