Outdoor PIR Motion Sensor 4 x 12m Coverage 180 Degree Ness

BRAND: Ness
SKU: 106-203
$500.20 List price: $666.90
+ −
30 Days Return Electricians Unlock Trade Access
Ness outdoor PIR motion sensor features 4 x 12m coverage, 180 Degree angle and day and night operation. Ideal for outdoor alarm systems.

Alternatively Known As: Takex MS-100E Outdoor PIR, Multi-Pattern Passive Infrared Sensor, Outdoor Alarm Motion Detector

Technical Specifications
  • Detection Technology: Passive infrared (PIR)
  • Coverage: Wide angle and vertical curtain up to 12m; long range up to 20m
  • Detection Angle: 180° rotatable sensor head
  • Supply Voltage: 10.5–30V DC, non-polarity operation
  • Current Consumption: 30mA maximum
  • Alarm Output: Selectable normally open or normally closed dry-contact relay
  • Tamper Output: Normally closed dry-contact relay
  • Sensitivity Adjustment: Approximately 30% to 170%
  • Operating Temperature: -20°C to +50°C
  • Installation Height: 0.8–1.5m for vertical outdoor installation
  • Housing Materials: PE resin cover and AES resin body
  • Weather Protection: Rain-resistant housing for outdoor or semi-outdoor installation
  • SKU: 106-200
  • Dimensions (H x L x W): 77mm x 171mm x 70mm
  • Weight: 0.22 kg
Key Features
  • Selectable wide-angle, curtain and long-range detection patterns
  • Supplied with interchangeable lenses for multiple coverage configurations
  • 180° rotatable optics for flexible vertical or horizontal positioning
  • Adjustable sensitivity and pulse count
  • Adjustable lux sensor for day, night or selectable operation
  • Selectable normally open or normally closed alarm output
  • Suitable for outdoor alarm, lighting and automation applications
  • Operation LED illuminates during alarm detection
Professional Installation Requirements
  • Installation should be performed by a suitably qualified security installer. Connect only to a compatible extra-low-voltage alarm, lighting or automation circuit and follow the manufacturer's installation instructions. Outdoor mounting should avoid direct rainfall, direct sunlight and exhaust vents.
Applications
  • Outdoor intruder alarm systems
  • Perimeter and approach monitoring
  • Automatic outdoor lighting control
  • Security camera or illuminator activation
  • Home automation and access-control applications
Standards & Compliance
  • AS/NZS 2201.1:2007 is the applicable Australian/New Zealand standard for the design, installation, commissioning and maintenance of intruder alarm systems incorporating detection devices; product-specific compliance was not identified.
Environmental Benefits
  • Low-voltage operation helps limit energy consumption in connected alarm and automation systems
  • Can activate lighting or surveillance equipment only when movement is detected, supporting energy-efficient operation
  • Durable polymer housing supports extended service life and reduced replacement waste
  • PE and AES housing materials may be recyclable subject to local plastics-recycling facilities
Warranty Information

Takex documentation states a 12-month limited warranty from the original date of shipment against defects in materials and workmanship. Ness separately lists a general 3-year warranty for Ness manufactured or supplied products; confirm the applicable warranty with the supplying distributor.

Available Now

Available through Ness and authorised Australian security-equipment distributors, subject to distributor stock.
