Overload Relay 10-14A | Adjustable Current Range | Manual & Automatic Reset | Trip Class 10 | @Quantity of 1 | by Clipsal
The Overload Relay 10-14A is designed for reliable motor protection in industrial automation, featuring an adjustable current range of 10-14A and both manual and automatic reset options. With a trip class of 10 for fast response and phase failure sensitivity, this relay ensures optimal performance in control panels, HVAC systems, and more.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Overload Relay 10-14A | Adjustable Current Range | Manual & Automatic Reset | Trip Class 10 | @Quantity of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLR2K0321
Alternatively Known As: Motor Overload Relay, Thermal Overload Relay, 10-14A Overload Protector, SCHLR2K0321 Relay
Technical Specifications
- Current Range: 10-14A adjustable
- Trip Class: 10
- Reset: Manual and automatic
- Mounting: Direct to contactor
- Phase Failure Sensitivity: Yes
- Auxiliary Contacts: 1 NO + 1 NC
- Operating Temperature: -20°C to +60°C
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 80mm x 70mm x 45mm
- Weight: 0.25 kg
Key Features
- Adjustable current range: 10-14A
- Manual and automatic reset options
- Trip class 10 for fast response
- Phase failure sensitivity
- Direct mounting to contactors
- Reliable protection against overloads
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure correct integration with motor starters and compliance with Australian electrical standards.
Applications
- Motor protection in industrial automation
- Control panels for machinery
- HVAC systems
- Pumps and compressors
- Conveyor systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Prevents motor damage, reducing equipment waste
- Enhances energy efficiency by protecting motors from excessive current draw
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Overload Relay 10-14A SCHLR2K0321 is available for immediate purchase. Ideal for industrial motor protection and automation panels.
