PAC50-ACC Pressure Transmitter | Gauge Pressure Sensor | -1 to 0 Bar Range | IP65/IP67 Rated | by SICK
The PAC50-ACC Pressure Transmitter is designed for precise gauge pressure measurement in industrial automation and process control. With a measuring range from -1 bar to 0 bar and overpressure safety up to 5 bar, it ensures reliable performance in pneumatic systems. Featuring an LCD display with LED backlight and high accuracy of ≤ ±1.5% span error, this sensor is perfect for optimizing compressed air system efficiency.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Medium: Dry compressed air
- Pressure type: Gauge pressure
- Measuring range: -1 bar to 0 bar
- Overpressure safety: 5 bar
- Process temperature range: 0 °C to +60 °C
- Output signal: 2 x PNP/NPN/Push-Pull + 4 mA to 20 mA / 0 V to 10 V
- Zero point adjustment: Max. +5% of span
- Display: LCD with LED backlight, rotatable 180°, pressure units selectable (bar, MPa, kPa, psi, inHg)
- Supply voltage: 17 V DC to 30 V DC
- Power consumption: Max. 40 mA at 24 V DC
- Electrical safety: Protection class III, overvoltage protection 32 V DC, short-circuit and reverse polarity protection
- Enclosure rating: IP65 and IP67
- Accuracy: ≤ ±1.5% of span
- Non-linearity: ≤ ±0.5% of span (BFSL)
- Non-repeatability: ≤ ±0.2% of span
- Setting accuracy of switching outputs: ≤ ±0.2% of span
- MTTF: 243.72 years
- Dimensions (H x L x W): 50mm x 100mm x 50mm
- Weight: 0.1 kg
Key Features
- Measures gauge pressure from -1 bar to 0 bar
- Overpressure safety up to 5 bar
- Output signals: 2 x PNP/NPN/Push-Pull plus 4 mA to 20 mA / 0 V to 10 V
- LCD display with LED backlight, rotatable 180°
- High accuracy with ≤ ±1.5% span error
- IP65 and IP67 rated enclosure for robust protection
- Short initialization time of 300 ms
- Automatic detection and programmable output signals
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection and calibration according to system requirements.
Applications
- Industrial automation and process control
- Monitoring gauge pressure in pneumatic systems
- Dry compressed air pressure measurement
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Enables precise pressure monitoring to optimize compressed air system efficiency, reducing energy waste.
- Durable IP65/IP67 housing extends product life, minimizing electronic waste.
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK PAC50-ACC Pressure Sensor is available for immediate purchase, ideal for industrial and automation applications requiring precise gauge pressure measurement.
