Pancake Pressure Vessel | Dual Access Connection | Anti-Corrosion Finish | by Aspen Pumps
The Pancake Pressure Vessel is designed for commercial and industrial refrigeration systems, featuring a dual access connection for easy monitoring and a solid core block composition for superior moisture absorption. Built to comply with ISO/AS 5149.2 standards, it enhances system efficiency by filtering harmful particles, making it ideal for R-22, R-410A, R-404A, and R-134A refrigerants.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pancake Pressure Vessel | Dual Access Connection | Anti-Corrosion Finish | by Aspen Pumps
Brand: Aspen Pumps
SKU: 303P-405S
Alternatively Known As: SKY Pressure Vessel Pancake, Refrigeration Pressure Vessel, Aspen Pancake Filter Drier
Technical Specifications
- Capacity kW R-22/410A: 18 kW
- Capacity kW R-404A: 16 kW
- Capacity kW R-134A: 13 kW
- Connection size: 5/8 inch ID with dual access
- Solid core block composition: 60% MS, 35% AL, 5% AC
- Safe Working Pressure (SWP): 3,200 kPa
- Manufactured to ISO/AS 5149.2 standards
- Dimensions (H x L x W): 108mm x 108mm x 88mm
- Weight: 1.5 kg
Key Features
- Connection: 5/8 ID - Dual Access
- Lay-in length: 108 mm
- Diameter: 88 mm
- Solid core block of 60% MS, 35% AL, 5% AC for superior acid, wax, and moisture absorption
- Membrane filter element removes and retains all harmful particles
- Anti-corrosion powder coat finish with chrome flare or solid copper connections
- Dual access ports to monitor pressure differential and contaminant take-up
- Manufactured in accordance with ISO/AS 5149.2
- Safe working pressure (SWP) of 3,200 kPa
Professional Installation Requirements
- Installation should be performed by a qualified HVAC technician or refrigeration professional to ensure compliance with safety standards and optimal system performance.
Applications
- Refrigeration systems requiring pressure vessels for refrigerants R-22, R-410A, R-404A, and R-134A
- Commercial and industrial HVAC systems
- Systems requiring contaminant filtration and moisture absorption
Standards & Compliance
- Complies with AS/NZS 5149.2 for refrigeration systems safety and performance
Environmental Benefits
- Enhances system efficiency by removing harmful particles and moisture, reducing refrigerant leaks and environmental impact
- Durable anti-corrosion finish extends product life, reducing waste
Warranty Information
Warranty details available upon request from Aspen Pumps, typically covering manufacturing defects.
Available Now
The Aspen Pumps SKY Pressure Vessel Pancake model 303P-405S is available for immediate purchase, ideal for commercial and industrial refrigeration applications.
