Pancake Pressure Vessel | Dual Access Connection | Anti-Corrosion Finish | by Aspen Pumps
The Pancake Pressure Vessel is designed for commercial and industrial refrigeration systems, featuring a dual access connection for easy monitoring and an anti-corrosion finish for enhanced durability. With a safe working pressure of 3,200 kPa, it effectively filters harmful particles and moisture, ensuring optimal system efficiency and prolonged equipment life.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Pancake Pressure Vessel | Dual Access Connection | Anti-Corrosion Finish | by Aspen Pumps
Brand: Aspen Pumps
SKU: 303P-406S
Alternatively Known As: SKY Pressure Vessel Pancake, Refrigerant Pressure Vessel, HVAC Pressure Vessel, Refrigeration Filter Vessel
Technical Specifications
- Capacity kW R-22/410A: 21 kW
- Capacity kW R-404A: 20 kW
- Capacity kW R-134A: 17 kW
- Safe Working Pressure (SWP): 3,200 kPa
- Manufactured to ISO/AS 5149.2 standards
- Material composition: 60% MS, 35% AL, 5% AC solid core block
- Connection size: 3/4 inch ID dual access
- Dimensions (H x L x W): 108mm x 108mm x 88mm
- Weight: 1.5 kg
Key Features
- Connection: 3/4 ID - Dual Access
- Lay-in length: 108 mm
- Diameter: 88 mm
- Solid core block composed of 60% MS, 35% AL, 5% AC for superior acid, wax, and moisture absorption
- Membrane filter element removes and retains all harmful particles
- Anti-corrosion powder coat finish with chrome flare or solid copper connections for ease of installation and increased service life
- Dual access ports to monitor pressure differential and contaminant uptake
- Manufactured in accordance with ISO/AS 5149.2 with a Safe Working Pressure (SWP) of 3,200 kPa
Professional Installation Requirements
- Installation should be performed by a qualified HVAC technician or licensed professional to ensure compliance with safety and regulatory standards.
Applications
- Refrigeration systems requiring pressure vessels for refrigerants R-22, R-410A, R-404A, and R-134A
- Commercial and industrial HVAC systems
- Systems requiring moisture and contaminant filtration in refrigerant lines
Standards & Compliance
- Complies with AS/NZS 5149.2 – Refrigerating systems and heat pumps – Safety and environmental requirements
Environmental Benefits
- Enhances system efficiency by removing harmful particles and moisture, reducing refrigerant leaks and environmental impact
- Prolongs equipment life, reducing waste and resource consumption
Warranty Information
Warranty details available upon request; typically includes coverage against manufacturing defects.
Available Now
The Aspen Pumps SKY Pressure Vessel Pancake model 303P-406S is available for immediate purchase, ideal for commercial and industrial refrigeration and HVAC applications.
